RWR - LINES FOR BARS - DEM

LINES FOR BARS
WITH PULLING
BLOCK

PERFORMANCE FEATURES
Finished wire diameters: 3.4 – 16 mm Rolling speed: up to 10 m/s Bar length: 0.6 – 15 m
MECHANICAL FEATURES
1 to 4 pulling blocks Straightening unit with manual or automatic adjustments DEM innovative high-speed shear Single or double bars unloading bench Automatic bundling station – option Discover more about DEM innovative technological packages

LINES FOR BARS
WITH DIRECT
ROLLING HEAD

PERFORMANCE FEATURES
Finished wire diameters: 4 – 16 mm Rolling speed: up to 5.5 m/s Bar length: 0.6 – 15 m
MECHANICAL FEATURES
Direct rolling head Straightening unit with manual or automatic adjustments DEM innovative high-speed shear Single or double bars unloading bench Automatic bundling station – option Discover more about DEM innovative technological packages

DEM HIGH
PERFORMANCE
LINES FOR BARS

PERFORMANCE FEATURES
Cutting performance: 150 bars/min Finished wire diameter: 3.4 – 16 mm Rolling speed: up to 10 m/s Bar length: 0.6 – 15 m
MECHANICAL FEATURES
2x faster than market average Perfect straightening with automatic straightening unit Suitable to feed any type of mesh welding machine Discover more about DEM innovative technological packages

AUTOMATIC
BUNDLING
STATION

PERFORMANCE FEATURES
Bundles dimensions: 150 to 400 mm Wraps: tight and loose type / single or double turn Binding wire (diameter): 6 - 7 mm
MECHANICAL FEATURES
Tying wir feeding assisted by a dancing wheel Binding head provided of pinch roll, twisting unit, wire guides and all auxiliary parts
